Fusarium wilt of banana


Fusarium wilt at a glance
Common name of the disease

Fusarium wilt

Causal agent

Fusarium oxysporum f. sp. cubense

Distribution
Race 1: pan-tropical
Tropical race 4: southeast Asia, northern Australia, Middle East and Mozambique

Fusarium wilt of banana, popularly known as Panama disease, is a lethal fungal disease caused by the soil-borne fungus Fusarium oxysporum f. sp. cubense  (Foc). The fungus enters the plant through the roots and colonizes the xylem vessels thereby blocking the flow of water and nutrients. Disease progression results in the collapse of leaves at the petiole, the splitting of the pseudostem base and eventually plant death. Once established in a field, the fungus persists in soil for an indefinite period of time and cannot be managed using chemical pesticides. The solution best adapted to the continued production of bananas in infested soils is replacing susceptible cultivars by resistant ones. Fusarium wilt is the first disease of bananas to have spread globally.

The pathogenic isolates are classified into races based on the cultivars on which they cause disease. For example, the isolates that affect cultivars in the Gros Michel, Silk and Pome subgroups, among others, are classified as race 1. When Cavendish cultivars exhibiting symptoms of Fusarium wilt were first observed, the isolates were classified as race 4. They were later subdivided into subtropical race 4 (STR4) and tropical race 4 (TR4) to distinguish the strains that need predisposing factors to cause the disease from the ones that don't. The race concept has been criticized for being an imperfect measure of pathogenic diversity, but it is still considered useful to describe host reaction and new disease outbreaks[1].

Distribution

Although the disease probably originated in southeast Asia, the first recording of the disease was made in 1874 in Australia, where it was observed at Eagle Farm near Brisbane[2]. It was then reported from Panama in 1890. Within a decade the disease had spread to Costa Rica and subsequent outbreaks occurred in Surinam (1906), Cuba (1908), Trinidad (1909), Jamaica (1911), Honduras (1916) and Guatemala (1919). The disease has since been reported from most banana-producing countries.

The term tropical race 4 (TR4) is used to distinguish the fungal strains that readily cause Fusarium wilt on Cavendish bananas from the ones that require predisposing factors such as low temperatures and waterlogging to cause disease and have become known as subtropical race 4 (STR4). The strain associated with TR4 was identified in samples from Taiwan in 1990[3]. The vulnerability of Cavendish cultivars was highlighted when newly established plantations were decimated in Malaysia[4] and Indonesia in the early 1990s.

Since then TR4 has been found in the island of Borneo (in both the Malaysian and Indonesian parts of the island), other Indonesian islands (Papua province[5], Kalimantan[6], Halmahera, Java, Sulawesi and Sumatra), mainland China (Guangdong[7], Hainan[8], Guangxi, Fujian and Yunnan), the Philippines[9] and Australia (Northern Territory in 1997[10] and Queensland in 2015[11]). It was reported to be in Jordan[12] and Mozambique[13] in 2013, and in Pakistan[14] and Lebanon in 2015[15]. There are also reports that it is in Oman[16].

In India, symptoms of Fusarium wilt have also been observed in the Cavendish cultivar 'Grande Naine' in the absence of predisposing factors[17], with the difference that the vegetative compatibility group of the isolate (VCG0124) is normally associated with race 1[18].

For more details, see the section on race 4.

Symptoms

Main symptoms of Fusarium wilt

Fusarium wilt is a typical vascular wilt disease. The fungus invades the vascular tissue through the roots causing discolouration and wilting, eventually killing the plant. The progress of the internal symptoms can influence the first appearance of the external symptoms. The fruit do not exhibit any symptom.

The characteristic internal symptom of Fusarium wilt is vascular discolouration, which varies from pale yellow in the early stages to dark red or almost black in later stages. Internal symptoms first develop in the feeder roots, which are the initial infection sites. The fungus spreads to the rhizome and then the pseudostem.

Externally, the first signs of disease are usually wilting and yellowing of the older leaves around the margins. The yellow leaves may remain erect or collapse at the petiole. Sometimes, the leaves remain green, except for spots on the petiole, but still snap. The collapsed leaves hang down the pseudostem like a skirt. Eventually, all the leaves fall down and dry up.

Splitting of the base of the pseudostem is another common symptom. Other symptoms include irregular, pale margins on new leaves and the wrinkling and distortion of the leaf blade.

Infected suckers do not start showing symptoms of Fusarium wilt until they are about 4 months old, a situation that has contributed to the spread of the disease through planting material. The fruit does not show any specific disease symptoms.

Reddish to dark brown discoloration of the vascular system.
Reddish to dark brown discoloration of the vascular system.
Yellowing typically begins at the margin of the older leaves.
Yellowing typically begins at the margin of the older leaves.
Collapsed older leaves hanging down the pseudostem.
Collapsed older leaves hanging down the pseudostem.
Split pseudostem.
Split pseudostem.
Farmers may spread the Fusarium fungus by transplanting symptomless but infected suckers.
Farmers may spread the Fusarium fungus by transplanting symptomless but infected suckers.

Similar diseases

The leaf symptoms of Fusarium wilt can be confused with those of the bacterial disease Xanthomonas wilt. In plants affected by Fusarium, yellowing and wilting of the leaves typically progresses from the older to the younger leaves. The wilted leaves may also snap at the petiole and hang down the pseudostem. In plants affected by Xanthomonas, the wilting can begin with any leaf and the infected leaves tend to snap along the leaf blade.

In countries with Moko disease, which is caused by Ralstonia solanacearum race 2, and also causes vascular discoloration, it is possible to confuse the two diseases. Unlike Moko, Fusarium wil does not cause wilting and blackening of young suckers or a dry rot in the fruit. The first symptoms of Moko on rapidly growing plants are the chlorosis, yellowing and collapse of the three youngest leaves, not the older leaves as with Fusarium wilt. Finally, with Moko the vascular discoloration is concentrated near the centre of the pseudostem and not peripherally, which is common with Fusarium wilt.

Modes of transmission

The fungus is commonly spread through infected planting material, infested soil and water.

Planting material

Symptomless but infected suckers or rhizomes can transmit the disease when planted in a new area. Infected planting material is often responsible for the local, national and international spread of the disease. Certified tissue-culture plantlets should be free of the fungus and would not contribute to the spread of the disease.

Soil

The fungus can persist in soil for decades, even in the absence of bananas. It can survive in infested plant debris and in the roots of alternative hosts. Staff and visitors to a banana plantation have the potential of moving the fungus in or out through infested soil attached to vehicles, tools and shoes. Untreated soil used as a potting medium can transmit the fungus and animals can also move around fungal spores present in soil.

Water

Spores can be carried in surface run-off water. They can also contaminate irrigation reservoirs.

Control options

The fungus cannot be controlled using fungicides and cannot be eradicated from soil using fumigants.  Drainage, environmental conditions and soil type influence host-pathogen interactions. Soils that suppress the disease have been reported in Central America, the Canary Islands, Australia and South Africa. However, the chemical, biological and physical factors responsible for this phenomenon are not well understood.

Exclusion

In disease-free areas, using tissue-culture plantlets will prevent the spread of the disease through planting material. How long the plantation remains productive will depend on the efficiency of the quarantine and exclusion measures implemented to prevent the entry of the pathogen.

The spread of TR4 has encouraged the installation in plantations of strategically located foot and vehicle baths filled with surface sterilants (e.g Farmcleanse®, Sporekill® and Domestos®) to prevent the entry and/or exit of infested soil[19][20]. Following the detection of TR4 in Queensland, Australia, Biosecurity Queensland published a document on best practices to minimise the risk of spreading TR4[21].

Biological control

Crop rotation can be a viable option if the non-banana crop has anti-fungal activity. In China, farmers have been able to grow bananas in the presence of TR4 by rotating them with Chinese leek (Allium tuberosum)[22]. Chinese leeks has also been used as an intercrop[23]. Enhancing the microbial community to suppress the pathogen is also being explored[24].

Resistant cultivars

Once the fungus has become established, the solution best adapted to the continued production of bananas in infested soils is replacing susceptible cultivars by resistant ones. Gros Michel, Silk, Pome and Pisang awak cultivars are generally resistant to race 2 strains but susceptible to races 1 and 4 strains. Cavendish cultivars are generally resistant to races 1 and 2 strains but susceptible to race 4 strains. Plantain and East African highland bananas (EAHB) cultivars are generally resistant to race 1 strains.

The FHIA improvement programme has produced hybrids that are resistant to races 1 and 4, while the Taiwan Banana Research Institute (TBRI) has released Giant Cavendish tissue-culture variants (GCTCV) that display varying levels of resistance to TR4[25].

In field trials conducted in China, FHIA-01, FHIA-02, FHIA-18, FHIA-25, Pisang Jari Buaya, Rose (AA), and to a lesser extent GCTCV-119 and FHIA-03, have shown resistance to TR4[26]. Preliminary results from a field trial conducted in the Philippines in 2011-2012 suggest that EAHB and Plantain might be resistant to TR4. Most of the ITC accessions screened displayed little or no sign of Fusarium wilt[27]. The one exception was Ibwi (ITC1465[28]), whose ploidy (2x/3x)[29] suggests that the accession might not be representative of the Ibwi cultivar. It is possible that the wrong accession was introduced to the ITC. In a separate field trial conducted in the Philippines, only 1% of the GCTCV-219 plants exhibited symptoms of Fusarium wilt in the second crop cycle, whereas none of plants of the Cardava cultivar (Saba subgroup) did[30].

A transgenic strategy based on a new understanding of how the fungus operates is being tested in Australia[31].

Impact

Fusarium wilt is responsible for the demise of the export trade based on Gros Michel. By the turn of the 20th century Gros Michel was exported from the Caribbean and Central America, where large-scale plantations were carved out of virgin rainforest. The first losses followed soon after Fusarium wilt was reported in Panama and Costa Rica in the 1890s (the strains that cause disease on Gros Michel would later become known as race 1). Only the availability of vast areas of virgin land prevented an early collapse of the industry. The opening of new land to make up for the abandoned plantations (estimated at more than 40,000 ha[32]) allowed production to keep ahead of the disease. But as uninfected and accessible land became increasingly rare in the the mid-1950s, production costs in Central America soared.

Even though resistant cultivars had been identified as early as 1910, the export industry did not begin to replace the susceptible Gros Michel banana until the late 1950s[32]. The change was motivated by the entry of Ecuador as a major banana exporter in the 1950s[33]. To compete with the cheap Gros Michel from Ecuador, the infested soils of Central America were planted with resistant Cavendish cultivars. Gros Michel has not completely disappeared, however. It is still grown by smallholder farmers, in backyard gardens and mixed crop systems.

Race 1 also had an impact on the cultivation of Silk, Pome and Pisang Awak cultivars, while race 2 reduced the cultivation of Bluggoe, especially in Latin America. African banana farmers have been less affected by Fusarium wilt given how African Plantains and East African highland bananas are largely resistant to race 1 strains.

Meanwhile, the emergence of TR4 started affecting commercial plantations of Cavendish cultivars. In the 1960s, Taiwan had about 50,000 hectares of banana plantations and was the major banana exporter to Japan. By the early 2000s, it had about 6,000 ha left in cultivation[34]. In Indonesia and Malaysia, the arrival of TR4 in the early 1990s destroyed recently established export plantations within a few years[34]. The fungus did the same to the banana industry in Australia's Northern Territory[35].

In mainland China, a survey conducted in 2006 reported that about 6,700 ha had been severely affected by TR4 in Guangdong province[36]. A report from a 2012 visit to the southwestern of Guangdong, the island of Hainan and the region around Guangxi’s capital, Nanning, hints at extensive damage[37].

In the Philiipines, the Federation of Cooperatives in Mindanao (FEDCO) called on banana farmers affected by TR4 to grow oil palm in 2014[38], even as new banana plantations were being established[39]. Smallholder farmers growing Cavendish bananas for the export market are also impacted[40].

Research

In 1950, United Fruit (nowadays Chiquita) hired  Robert H. Stover to devise management strategies for Fusarium wilt, which by then was threatening the very existence of the export trade based on Gros Michel. Stover added new insights into the taxonomy, variation, and physiology of the fungus, helped describe its interaction with banana, characterized resistance and susceptibility in banana, studied the influence of edaphic factors on the pathogen, and introduced flood fallowing as a means for cleansing contaminated soil (a practice that was later shown to contribute to the spread of the fungus). Stover’s research culminated in 1962 with the publication of "Fusarial Wilt (Panama Disease) of Bananas and other Musa species".

The publication of Stover’s monograph coincided with the substitution of the susceptible Gros Michel with resistant Cavendish cultivars. With this transition came a dramatic reduction in research on the disease as the banana export industry turned its attention to more pressing problems, such as black leaf streak[41].

The spread of TR4 has spurred interest in research on Fusarium wilt. See efforts to address the threat of TR4.

References

1. Ploetz, R.C. and Churchill, A.C.L.. 2011. Fusarium wilt: the banana disease that refuses to go away. p.519-526. In: Van den Bergh, I., Smith, M., Swennen, R. and Hermanto, C. (eds.). Proceedings of International ISHS-ProMusa Symposium on Global Perspectives on Asian Challenges, Guangzhou, China, 14-18/09/2009. Acta Horticulturae 897. ISHS, Leuven, Belgium.
2. Bancroft, J. 1876. Report of the board appointed to enquire into the cause of disease affecting livestock and plants. In: Votes and Proceedings 1877, Vol 3, Queensland, pp. 1011-1038
4. Ong Kim Pin. 1996. Fusarium wilt of Cavendish banana in a commercial farm in Malaysia. p.211-217. In: Frison, E.A., Horry, J. and De Waele, D. (eds.). Proceedings of New Frontiers in Resistance Breeding for Nematode, Fusarium and Sigatoka, Kuala Lumpur (MYS), 1995/10/2-5. New frontiers in resistance breeding for nematode, Fusarium and Sigatoka. INIBAP, Montpellier (FRA).
5. Davis, R.I., Moore, N.Y., Bentley, S., Gunua, T.G. and Rahamma, S. 2000. Further records of Fusarium oxysporum f. sp. cubense from New Guinea. Australasian Plant Pathology 29(3):224.
6. Hermanto, C., Sutanto, A., HS, E., Daniells, J.W., O'Neill, W.T., Sinohin, V.G.O., Molina, A.B. and Taylor, P.. 2011. Incidence and Distribution of Fusarium Wilt Disease of Banana in Indonesia. Proceedings of the International ISHS-ProMusa Symposium on Global Perspectives on Asian Challenges held in Guangzhou, China, 14-18 September 2009. Van den Bergh, I., Smith, M. and Swennen, R. (eds). Acta Horticulturae 897:313-322.
7. Qi, P. 2001. Status report of banana Fusarium wilt disease in china. p.119-120. In: Molina, A.B., Nik Masdek, N.H. and Liew, K.W. (eds.). Proceedings of International Workshop on the Banana Fusarium Wilt Disease, Genting Highlands Resort, 1999/10/18-20. Banana Fusarium wilt management: Towards sustainable cultivation. INIBAP, Los Banos, Philippines.
8. Qi, Y.X., Zhang, X., Pu, J.J., Xie, Y.X., Zhang, H.Q. and Huang, S.L. 2008. Race 4 identification of Fusarium oxysporum f. sp. cubense from Cavendish cultivars in Hainan province, China. Australasian Plant Disease Notes 3(1):46-47
9. Molina, A., Fabregar, E., Sinohin, V.G., Herradura, L., Fourie, G. and Viljoen, A. 2008. Confirmation of tropical race 4 of Fusarium oxysporum f. sp. cubense, infecting Cavendish bananas in the Philippines. Abstract of presentation to the 2008 Centennial Meeting of the American Phytopathological Society
10. Conde, B.D. and Pitkethley, R.N. 2001. The discovery, identification and management of banana fusarium wilt outbreaks in the northern territory of Australia. p.260-265. In: Molina, A.B., Nik Masdek, N.H. and Liew, K.W. (eds.). Proceedings of International Workshop on the Banana Fusarium Wilt Disease, Genting Highlands Resort, 1999/10/18-20. Banana Fusarium wilt management: Towards sustainable cultivation. INIBAP, Los Banos, Philippines.
12. Garcia, F.A., Ordonez, N., Konkol, J., AlQasem, M., Naser, Z., Abdelwali, M., Salem, N.M., Waalwijk, C., Ploetz, R.C. and Kema, G. 2013. First Report of Fusarium oxysporum f. sp. cubense Tropical Race 4 associated with Panama Disease of banana outside Southeast Asia. Plant Disease.
16. News on agricultural quarantine measures on bananas in the 5 September 2012 edition of muscatdaily.com
18. A new threat to Cavendish bananas? published 8 March 2011.
19. Nel, B., Steinberg, C., Labuschagne, N. and Viljoen, A. 2007. Evaluation of fungicides and sterilants for potential application in the management of Fusarium wilt of banana. Crop Protection 26(4):697-705.
20. Meldrum, R.A., Daly, A.M., Tran-Nguyen, L.T.T. and Aitken, E.A.B. 2013. The effect of surface sterilants on spore germination of Fusarium oxysporum f. sp. cubense tropical race 4. Crop Protection 54:194-198.
21. Panama disease tropical race 4: Standards and guidelines published by Biosecurity Queensland, 20 May 2015 (PDF 655.3KB)
22. Growing Cavendish in the presence of TR4 in the 10 December 2012 issue of InfoMus@'s News and analysis section.
23. Nadarajah, H.et al. 2016. Effects of genotype and intercropping with Chinese chives (Allium tuberosum) on Fusarium wilt tropical race 4 in banana. p.153-160 in the Proceedings of ISHS-ProMusa Symposium: Unravelling the Banana's Genomic Potential held in Brisbane, Australia, 17-22 August 2014. Acta Horticulturae 1114.
25. Growing Cavendish in the presence of TR4 in the 10 December 2012 issue of InfoMus@'s News and analysis
26. Huang, B.Z., Xu, L.B. and Molina, A.B. 2005. Preliminary evaluation of IMTP-III varieties and local cultivars against Fusarium wilt disease in southern China. Proceedings of the 3rd BAPNET Steering Committee meeting held in Guangzhou 23-26 November 2004. A.B. Molina, V.N. Roa, I. Van den Bergh and K.H. Borromeo (eds). Advancing Banana and Plantain R&D in Asia and the Pacific, Vol. 13:187-191. INIBAP, Los Baños, Laguna, Philippines.
27. Risk assessment of Eastern African Highland Bananas and Plantains against TR4, a poster presented at the 2012 International Banana Symposium in Taiwan.
28. ITC1465 in MGIS
29. Ploidy of Ibwi in MGIS
31. Paul, J-Y., Becker, D., Dickman, M.B., Harding,R., Khanna, H. and Dale, J. 2011. Apoptosis-related genes confer resistance to Fusarium wilt in transgenic 'Lady Finger' bananas. Plant Biotechnology Journal 9(9):1141-1148.
32. Soluri, J. 2002. Accounting for Taste: Export Bananas, Mass Markets, and Panama Disease. Environmental History 7(3):386-404.
33. Stover, R.H. 1986. Disease Management Strategies and the Survival of the Banana Industry. Annual Review of Phytopathology, 24:83-91.
34. Molina, A.B., Fabregar, E., Sinohin, V.G., Yi, G. and Viljoen, A. 2009. Recent occurrence of Fusarium oxysporum f. sp. cubense Tropical Race 4 in Asia. Proceedings of the International ISHS-ProMusa Symposium on Recent Advances in Banana Crop Protection for Sustainable Production and Improved Livelihoods held in White River, South Africa, 10-14 September 2007. Jones, D.R. and Van den Bergh, I. (eds). Acta Horticulturae 828:109-116.
35. Conde, B.D. and Pitkethley, R.N. 2001. The discovery, identification and management of banana Fusarium wilt outbreaks in the Northern Territory of Australia. p.260-265. In: A.B. Molina, N.H. Nik Masdek and K.W. Liew (eds.), Banana Fusarium wilt Management: Towards Sustainable Cultivation. Proceedings of the International Workshop on the Banana Fusarium Wilt Disease held in Genting Highlands Resort, Malaysia, 18-20 October 1999. INIBAP, Los Baños, Laguna, Philippines.
36. Yi, G.J., Huang, B.Z., Xu, L.B., Chen, H.B., Hu, G.B., Xu C.X. and Molina A.B. 2007. Fusarium wilt threatens livelihoods of banana farmers in Southern China. p.1-2. In: A.B. Molina, J.T. Oliver, V.N. Roa and V.G.O. Sinohin (eds.), RISBAP Bulletin (July 2007) Volume 11, No. 2. Bioversity International Regional Office for Asia and the Pacific, Los Baños, Laguna, Philippines.
37. Farquhar, I. 2012. Bananas in China. Report on a visit to three banana producing provinces of China by Dr. Iain Farquhar on behalf of Banana Link and the Steering Committee of the World Banana Forum. 35 pp.
39. Banana plantation to rise around Maguindanao massacre site in the 22 March 2014 issue of GMA news online.
40. Videos on the experience of banana farmers in the Philippines, part 1 and part 2.
